CS-400 Zirconia Silicate Ceramic Grinding Media

Short Description:

Chemshun CS-400, Zirconia Silicate ceramic grinding media is an ultra high-performance, middle density, durable and cost effective ceramic grinding media, applications in stirred vertical mills and horizontal mills. With superior strength, high hardness, wear resistance and consistent particle size and shape characteristics, It is well suited to high speed milling process of mineral ores and similar hardness and provide unmatched economic and performance for you. In addition, small size Zirconium Silicate beads usually used as high-end blasting agents to polish and remove blemishes and flaws.


Product Detail

Features and Benefits

1.Compact crystal structure: high strength, low wear loss.
2.High spherical degree: good fluid, high throughput of slurry.
3.Special formula: high density, high grinding efficiency.
4.Smooth spherical surface: easy to clean, low abrasion to equipment.
5.Solid ball: quite durable.
6.Uniform internal structure, low beads wear, narrow particle size to grinded material.



Application of Zirconia Silicate Beads

1.Paint and coating material: anti-corrosive industry paint, plastic paint, emulsion, paint, printing ink ,ink-jet ink, paper coating material, tape and disk coating.
2. Pesticide: insecticide ,herbicide, antiseptic, seed coating agent.
3. Pigment and dye: dispersing and grinding of titanium pigment, carbon black, inorganic pigment like iron oxide red, organic pigment.
4. Chemical filling material: bolus alba ,titanium, mica, talcum.
5. Metal mining such as lead, copper, zinc.



Chemical and Physical Property

No.

Property

Unit

Data

1

ZrO2

%

54-65

SiO2

%

30-35

2

Specific Gravity

g/cc

4.0-4.2

3

Package Density

Kg/l

>2.4

4

Vickers Hardness(HV)

>1000

5

Water Absorption

%

<0.01

6

Wear Loss

g/kg.h

<1.0

7

Color

White



Normal Size (mm)

Diameter

Diameter

Diameter

Diameter

0.4-0.6

1.0-1.2

1.6-1.8

2.2-2.5

0.6-0.8

1.2-1.4

1.8-2.0

2.5-3.0

0.8-1.0

1.4-1.6

2.0-2.2

6-20



Package term

1. 25kg net in PP bag or
2. Big bag of 500 or 1000kg net.
Around 20-24MT/20′ FCL.
If you hope to get a quick feedback, please send us these detail information, then our team will supply you a full and soon reply:
1.Your application industry.
2. Your Grinding efficiency requirement.
3. Your target price.
4. Sample quantity, bulk order quantity.
5. If you need customized products, please send us the specific composition, size and drawings.

Once you have any questions or need more information, please kindly contact with Chemshun.
